Heavy Duty Modular Connector Wiring Harness (HARTING Han-Modular Series) Rated Voltage: AC 250V / DC 600V Rated Current: Signal circuit 10A, High-power circuit 30A Wire Gauge: 18AWG~22AWG signal wire, 16AWG high-voltage power wire Operating Temperature: -40℃ ~ +125℃

Specifications

1. Rated Voltage: AC 250V / DC 600V
2. Rated Current: Signal circuit 10A, High-power circuit 30A
3. Wire Gauge: 18AWG~22AWG signal wire, 16AWG high-voltage power wire
4. Operating Temperature: -40℃ ~ +125℃
5. Shielding: Equipped with anti-interference ferrite bead, low EMI radiation
6. Connection Type: Crimp terminal + Ring terminal cold-pressed connection

Mechanical & Structure Specifications

1. Connector Type: Han-Modular combined heavy-duty rectangular connector
2. Number of Circuits: Multi-pin mixed signal + power composite circuits
3. Protection Grade: IP65 (mated closed state)
4. Wire Processing: Heat-shrink tube sealed insulation, cable reinforcement & strain relief structure
5. Assembly: Integrated metal locking housing, anti-loosening screw fastening
6. Terminal Treatment: Tin-plated copper crimp contact, anti-oxidation & corrosion resistant

Material & Environmental Specifications

1. Cable Insulation: Low-smoke halogen-free flexible industrial cable
2. Housing Material: Die-cast zinc alloy + PA66 engineering plastic
3. Adapt Working Condition: Industrial automation, EV vehicle control system, new energy equipment connection
4. Compliance Standard: IEC 61984, UL certification, RoHS environmental protection
