7.84 inch IPS 480*1280 LCD Display
. LCD type
7.84 inch
. Resolution (H*V)
400*(RGB)*1280 .
Technology Type
a-Si TFT
Display . Spec.
Pixel Configuration
R.G.B.Vertical Stripe .
Normally Black .
Viewing Direction:
ALL .
OutlineDimensions(W×H×T)(mm):
67.8*206.18*4.6 .
Active Area(mm):
59.4*190.08
.With Mithout Touch screen .
Connector Type:
40PIN 0.5PITCH .
Backlight Type:
LED
. Interface
MIPI 4lane
.Driver IC
NV3051
