14*2 Monochrome LCD Display
Get a Quotation
Overview
Key Features
Applications
Specifications
Download
14*2 Monochrome LCD Display
Item
Standard Value
Display Type
16characters 4 lines
LCD Type
STN，NEGATIVE（BLUE）,TRANSMISSIVE
Driver Condition
LCD Module : 1/16Duty , 1/5Bias
Viewing Direction
6 O’clock
Backlight Type
SIDE WHITE
Interface
8-bit MPU interface
Driver IC
AIP31066L
Mechanical Specifications
Item
Standard Value
Unit
Outline Dimension
87(L) * 60(W) * Max 12.8(T)
mm
Viewing Area
62(L) * 26( W)
mm
Dot size
0.55(W) 0.55(H)
mm
Dot pitch
0.6(W) 0.6 (H)
mm
Character size
4.75(W) 2.95(H)
mm
